24 GPM Ultraviolet Water Sterilizer System,
manufactured in Aqua SoftPro Taiwan flow reactors in 304 stainless steel and come with 1.5″ MNPT connections. The hard glass germicidal lamps provide an economical way of treating water requiring a 99.99% reduction of bacteria and virus.
24 GPM Ultraviolet Water Sterilizer System
manufactured in Aqua SoftPro Taiwan flow reactors in
304 stainless steel and come with 1.5″ MNPT
connections. The hard glass germicidal lamps provide
an economical way of treating water requiring a 99.99%
reduction of bacteria and virus.
• Aqua SoftPro UV STANDARD FEATURES
• Heavy-duty stainless-steel pressure vessel
• Heavy duty quartz sleeve
• High output, hard glass UV lamps for maximum efficiency
• CE ballast with lamp failure indicator and warning buzzer
• Ceramic end cap of UV lamp
• 30000mic. watt sec/cm2 at energy of 253.7nm wave length
• Working pressure 125PSI
• Low power consumption
• 9000 hours lamp life (approx. 1 year of use)
• 110/220V, 50HZ/60HZ
• Vertical or Horizontal installation
What is a Water Softener?
A water softener is made up of three main components:
- Control Valve– determines when regeneration is necessary, the direction of water flow and the amount of time spent in each cycle
- Pressure Tank– holds the resin that exchanges sodium for hardness minerals and is under water line pressure
- Salt Tank or Cabinet– holds the salt that makes the brine solution used to regenerate the softening resin
1. Pure Water, Perfect Health!
Ensure safe and clean drinking water with the 400 GPD UV water
filtration system. Order now in UAE for instant access to fresh, purified
water!
2. Say Goodbye to Contaminants!
Protect your family with the advanced 400 GPD UV water filtration
system. Get yours today in Jeddah for cleaner, healthier water at home!
3. Trustworthy Water Purification at Your Fingertips!
Experience the power of UV filtration for crystal-clear water. Contact us
now to install the 400 GPD system in your UAE home! 00971- 504630049
- Capacity and Flow Rate
- Capacity: Measured in grains, gallons, or liters, indicating the amount of hardness the system can handle before regeneration is needed. Common capacities range from 20,000 to 80,000 grains.
- Flow Rate: The maximum amount of water the system can process per minute or hour. Flow rates vary based on household size and water usage, typically ranging from 4 to 20 gallons per minute (GPM).
- Type of System
- Salt-Based Softeners: Utilize salt or potassium to regenerate the resin beads. They are the most common and effective for removing hardness.
- Salt-Free Softeners: Use alternative technologies such as template-assisted crystallization or other methods to prevent scale buildup rather than removing hardness.
- Resin Tank
- Material: Usually made from durable, corrosion-resistant materials like fiberglass or high-density polyethylene (HDPE).
- Resin Type: Contains ion-exchange resin beads that attract and remove hardness minerals from the water.
- Brine Tank
- Capacity: Varies depending on the system size, typically ranging from 100 to 500 pounds of salt.
- Material: Generally made from plastic or fiberglass.
- Features: May include an automatic float valve to prevent overflow and ensure proper salt levels.
- Control Valve
- Type: Can be manual, semi-automatic, or fully automatic. Automatic valves are the most common, managing regeneration cycles based on water usage and hardness levels.
- Regeneration Cycle: Determines how often and when the system regenerates. Can be based on time, volume of water treated, or a combination of both.
- Bypass Valve
- Function: Allows you to bypass the softener when needed, such as during maintenance or if softened water is not required.
- Installation Requirements
- Connection Size: Typically comes with inlet and outlet ports in standard sizes like 1″ or 1.5″.
- Space Requirements: Requires sufficient space for the resin tank and brine tank, as well as access to a drain for discharge during regeneration.
- Dimensions
- Size: Varies based on system capacity, but typical dimensions for residential systems might be around 10-15 inches in diameter and 40-60 inches in height.
- Efficiency
- Salt Efficiency: Measures how much salt is used per regeneration cycle. Higher efficiency models use less salt to achieve the same level of hardness removal.
- Water Usage: Measures how much water is used during regeneration. More efficient systems use less water.
- Additional Features
- Smart Technology: Some modern systems come with digital controls and Wi-Fi connectivity for remote monitoring and adjustments.
- Built-In Filter: Some systems include additional filtration stages to remove sediment or chlorine.
- Durability: Made from high-quality, corrosion-resistant materials to ensure long-term reliability.
- Warranty and Support
- Warranty: Typically includes a warranty period for the tank, control valve, and resin, ranging from 1 to 5 years.
- Customer Support: Access to customer service and technical support for installation and troubleshooting.
- +971-50 4630049 = 24/7 Call about it
- Maintenance Requirements
- Salt or Potassium Refill: Regular refilling of the brine tank with salt or potassium.
- Resin Replacement: Resin beads may need replacement every 2 years depending on water quality and usage.
These specifications help ensure that a water softener system is effective, efficient, and suited to your specific needs for treating hard water.
We Offer
- 1 Year Machine Warranty for all parts
- 1 Year Free Service with Pree Filter Free Change
- Free Delivery & Installation
- Including the following Accessories:
Aqua SoftPro 48 GPM-HTM UV-Ultraviolet
1.Dimension LxWxD (mm) 980X230X280 H-HT-HTM
2.Electrical Volts: 110/220V / 50/60HZ
3.Flow Rate : 48-GPM
4.In/out Port : 1-1/2”
5.UV Lamp (PC) : 4
6.Quartz Sleeve (PC) : 4
7.Lamp Failure Device : Yes
8.Ambient Temperature : 2-50oC
9.Lamp Watts : 40wx4
10.Chamber : SS304
